DEIF ASC-4 Variant 07 Battery Controller with Display

DEIF ASC-4 Variant 07 Battery Controller with Display

Part NoASC-4 Variant 07
MOQ1 Unit
Shipped & sold bySunhub Managed
Shipping TypeEXW - Ex Works (Place)
LocationChicago, IL
ConditionNew
Asking Price Per Unit:
Quote on request
Quantity on Hand0 Units
View Negotiable Terms
Product Information

DEIF Logo

DEIF ASC-4 Variant 07 Battery Controller with Display

"Note: Lead Time: 2-3 weeks" \ Please contact for quantity

The products are highly configurable

ASC-4 Battery with display + J1 + H2

The ASC-4 Battery controller can be used as a single controller to add a storage system to an existing site, or with other DEIF controllers in a power/energy management system. The ASC-4 Battery controller controls and protects an energy storage system (ESS) with communication to a BCU, PCS, PDS and BMS. The ASC-4 Battery controller can instruct all gensets to stop, and supply the load from battery alone or in combination with sustainable power production.

Options:

  • H2: Serial communication Modbus
  • J1: Display cable with plugs, 3 m with 2 x ferrit
  • J4: PC cable for option N-programming
  • Y16: Battery control

Key Features:

  • Single Battery Controller -without power management communication to other controllers. Single controllers are particularly useful for brownfield applications. Single controllers can also be used in greenfield applications.
  • External gensets
  • External mains
  • Energy storage breaker (ESB) control (optional)
  • External power source (for example, genset) start and stop by an external relay, based on: State of charge (SOC) & System load
  • Ideal for ESS rental applications

Product Details:

  • Mfr Part Number: ASC-4 Variant 07
  • Product: ASC-4 Battery
  • Display: Standard Display DU-2
  • Weight: 5 lb
  • Dimensions: 6.5 x 9.6 x 8.5 in
Configurable possible options to add: Adding options will alter the price. Inquire for updated pricing if additional options are required.
F1: 2 analog transd. output, I1: Emulation, N: Ethernet TCP / IP, Q1: Verified class 0.5, T1: Critical Power
GOV / AVR: E2: 2 analog transd. output
Power Management: G5: Advance PMS
External Communication: H2: Serial comm. MOD-bus, H2.8: Serial comm. MOD-bus
Accessories: J1: Display cable w/plugs 3m, J2: Display cable w/plugs 6m, J4: Ethernet cable - 3m crossed, J7: USB cable - 3m, L: Display gasket
Binary and Analogue I/Os: M4: Engine control/protection, M12: 12xbin. inp./4xrelay outp., M13.2: 7xbinary input, M13.4: 7xbinary input, M13.6: 7xbinary input, M13.6: 7xbinary input, M13.8: 7xbinary input, M14.2: 4xrelay output, M14.4: 4xrelay output, M14.6: 4xrelay output, M14.8: 4xrelay output, M15.6: 4xanalog inp/4-20 mA, M15.8: 4xanalog inp/4-20 mA
