Outback Power FLEXmax 100A MPPT Solar Charge Controller
Quantity on Hand10 Units
View Negotiable Terms
Description
Specifications
Supporting Docs
Product Information
Outback Power FLEXmax 100A MPPT Solar Charge Controller
The OutBack Power FLEXmax 100 is a high-performance MPPT charge controller designed for reliable, mission-critical energy systems. It features a compact, outdoor-rated enclosure with built-in arc fault, ground fault, and rapid shutdown protection for enhanced safety. With 128 days of data logging, smart setup (via MATE3s), and OPTICS RE remote monitoring, it offers easy system management. Its advanced MPPT technology enables faster battery charging, improved energy harvest, and an excellent price-to-power ratio.
Key Features:
- 100A output for up to 6kW of charging
- Updated MPPT software algorithm improves energy harvest vs other controllers
- 300VDC open-circuit voltage limit enables 2-4 string configuration to minimize BOS
- Programmable auxiliary control output for smart load controls
- Standard 5 year warranty upgraded to 7,000W of nameplate solar power at 48V
- Integrated arc fault circuit detection and interruption for optimized systems
- The only fully NEC 2017 compliant charge controller solution
Product Details:
- Manufacturer Part Number: FM100-300VDC-AFCI
- Maximum Continuous Output Current: 100A
- Shipping Weight: 19.75 lb
- Dimensions: 26 x 12 x 10 in
- Warranty: 5 years
