Asking Price Per Unit:
$80.49
NEW
Powerfield PowerRack 1200 Fixed Tilt Ground Mount Solar Racking
Quantity on Hand22000 Units
View Negotiable Terms
Description
Specifications
Supporting Docs
Product Information
Powerfield PowerRack 1200 Fixed Tilt Ground Mount Solar Racking
NOTE: USA MADE.
PowerField Energy's PowerRack PV solar ground mount system is a revolutionary solution for low-cost low-impact versatile applications. This ballasted system requires no ground penetration and no tools, dramatically reducing costs and enhancing project flexibility.
Key Features:
- Fixed-tilt, single-module ground-mount racking system
- Designed for rapid field deployment and repeatable installation
- Not limited to gravel and soil-based site conditions (final design subject to geotechnical review)
- Structural capacities based on code-compliant loading assumptions and site-specific engineering
- Ballast Material: Aggregate gravel, sand, dirt (loose dry material under ¾")
- Not limited by site conditions. Can be installed on most terrains and slopes.
Product Details:
- Manufacturer Part Number : 299-1200-013
- Tilt Angle: 20°
- Module Orientation: Landscape
- Wind Load: 135 mph (ASCE 7-22) 185 mph+ with ground anchors
- Snow Load: 200+ psf (9,500+ Pa
- Pallet Qty: 50 Units
- Full Truckload: 1,200 units (24 pallets)
- Weight: 23.8 lb
- Dimensions: 44x25.59x 29.84 in
